DAS Audio VANTEC-12A 12" Active Speaker

The VANTEC-12A is a self-powered system with a multi-angle enclosure that allows for use as a stage monitor in addition to its typical compact PA application. Its 1500Wpeak Class D amplifier provides wide bandwidth, wide dynamic range, and exceptionally low distortion, uncommon in enclosures of this segment. Vantec self-powered systems incorporate digital FIR filters for signal processing. Users can select sound configurations, filters, EQ modes, and gain control via a single-control interface and LCD display on the rear of the enclosure. The 12F4 loudspeaker faithfully reproduces low frequencies. In the tweeter path, the FEM-optimized M-28 driver with a 1" exit delivers excellent performance.

• Frequency range (-10 dB): 60 Hz – 20 kHz.


• Horizontal coverage (-6 dB): 90º.


• Vertical coverage: 50º.


• Maximum SPL at 1m: 135dB.


• Amplifier power rating (continuous): 750 watts.


• Amplifier power rating (peak): 1500 watts.


• Input type: Balanced.


• Input impedance: 20 kilohms.


• Input sensitivity: 3 V (+12 dBu).


• Audio signal input connector: 2 x XLR female.


• Auxiliary input: 1 x 3.5mm mini jack.


• Audio signal loop through connector: 1 XLR male.


• Control: DASlink™, DAScontrol™.


• Power consumption: 230 V / 115 V, 1.2 A/2.4 A.


• This product has a 1-year warranty against factory defects.
