PRO STAGE FRESNEL PROLIGHT Led Wash Lamp

The PRO STAGE FRESNEL is made of a new type of high-temperature resistant die-cast aluminum housing with a good outlook. The fixture is designed and manufactured strictly following CE standards, complying with the international standard DMX512 protocol. It is available independently and can be linked together for operation. And it is applicable for large-scale live performances, theater, studio, nightclubs, and discos. The PRO STAGE FRESNEL adopts 1PCS 300W COB LEDs (Warm White available) which features high brightness and stability.

• 1 * 300W COB LED (warm white).


• 50,000 hours of lifespan and low energy consumption.


• Color Rendering Index (CRI): Ra≥ 90.


• High efficiency Fresnel lens.


• 15°-50° manual zoom system.


• Housing made of durable, die-cast aluminum alloy.


• Thermally insulated rear handle.


• Heat-insulated knobs with a single aluminum handle for installation.


• Barndoors or cutters included.


• Color frame as optional.


• Smooth and precise 0-100% linear dimmer.


• Preset variable/random strobe effect and dimming pulse.


• 1/2 DMX channels USITT DMX-512.


• DMX512, master-slave and sound control or automatic operation.


• 4-button LCD display.


• POWERCON IN/OUT connector.


• Power switch available with fuse.


• 3 and 5 pin XLR IN/OUT connectors.


• Integrated low noise fan with copper liquid cooling system.


• Maximum ambient temperature -10-40°C.


• IP20 protection rating.


• 1 * Safety fixing point. Input voltage: AC90-260V 50/60Hz.


• LED Quantities: 1*300W(Warm White).


• Control signal: DMX512, master-slave and sound activated or auto operation.


• Control channel: 1/2 DMX channels USITT DMX-512.


• Power consumption: 390W.


• This product has a 1-year warranty against factory defects.
